Platform stairlift (Wheelchair stairlift)

X3 is the platform stairlift designed to allow for straight internal and external staircases in total autonomy and simplicity.
A perfect wheelchair lift that stands out for its quietness and compactness, X3 therefore represents the ideal solution to guarantee accessibility both in single-family homes and in condominium and commercial buildings.
X3 can accommodate a person in a wheelchair or a seated person thanks to the comfortable folding seat applicable to respond to different mobility needs.

Description

Applications Straight Stairways indoor and outdoor. Residential or commercial.
Maximum rail length 10 m
Inclination 20° – 45°
Speed max 0,07 m/s
Drive System Rack & Pinion
Platform sizes
640×680 mm ; 700×750 mm ; 800×800 mm ; 800×900 mm; 800x1050mm;
800x1220mm.
(Customized sizes upon request).
Power Requirements
Batteries. 24 Vcc
(2 batteries 12 V, 7,2 Ah – optional 18 Ah).
Rated Load 250 kg.
Platform Controls
Keyless with continuous pressure directional buttons, lighted direction buttons,
emergency stop switch. Attendant remote control with cable (On request).
Floors controls Wireless call stations activable/disactivable with keys
Fixing systems Fixing on step, wall, mixed.
Safety
Stop button, anti-fall safety arms (automatic or manual), Under platform obstruction
detection, Running direction ramp sensing, Pedestrian safety lights, speed limiter.
Conformity 2006/42/CE, 2014/30/CE, 2014/35/CE, EN 81-40:2008
